Power Supply, Primary Switch Mode, Narrow Design – MINI-PS-100-240AC/5DC/3
General Data
Isolation voltage: Input/output
Approval package
Safety transformers for switched-mode power supplies
Electrical safety
(of IT equipment)
Industrial control equipment
Equipping high voltage installations
with electronic equipment
Safety extra-low voltage
Safe isolation
Protection against electric shock
Protection against dangerous shock currents,
basic requirements for safe isolation
in electrical equipment
Limitation of harmonic line currents
Mounting position
4 kV AC (type test)/3 kV AC (routine test)
EN 61 558-2-17
EN 60950/VDE 0805
UL/C-UL Recognized UL 60 950 u 1)
U
UL/C-UL Listed UL 508 LISTED 1)
EN 50 178/VDE 0160 (Surge Voltage Category III)
PELV (EN 50 178)
SELV (EN 60 950)
VDE 0100-410
DIN 57 100-410
DIN VDE 0106-101
According to EN 61000-3-2
On horizontal NS 35 DIN rail according to EN 50022
Can be mounted with spacing
- Vertical
≥ 8 cm (0.31 in.)
Degree of protection
Class of protection
MTBF
Housing version
Dimensions (W x H x D)
Weight
Climatic Data
- Horizontal
0 cm
IP 20
ΙΙ , (in closed control cabinets)
> 500 000 h according to IEC 1709 (SN 29 500)
Polyamide PA, color green
(22.5 x 99 x 114.5 mm [0.886 x 3.898 x 4.508 in.])
0.17 kg, approximately
Ambient temperature
Operation
-25°C to +70°C (-13 ? F to +158 ? F) (> +60°C [+140 ? F] derating)
Humidity
Storage
-40°C to +85°C (-40 ? F to +185 ? F)
up to 95% at +25°C (+77 ? F), no condensation
Vibration
Shock
according to IEC 68-2-6
according to IEC 68-2-27
< 15 Hz, amplitude ±2.5 mm/15 Hz - 150 Hz, 2.3 g
30 g all space directions
UL approval for AC input voltage and ambient temperature up to
Degree of pollution
Climatic category
c
Conforms to the EMC Directive 89/336/EEC and the
Low Voltage Directive 73/23/EEC
EMC (Electromagnetic Compatibility)
2 (according to EN 50 178)
3K3 (according to EN 60 721)
1)
+60°C (+140°F)
Requirements
Noise Immunity According to EN 61000-6-2:
EN 61 000-6-2
MINI-PS-100-240AC/5DC/3
EN 61000-4-2
Electrostatic discharge
3)
Housing
Level 3
(ESD)
Contact discharge:
Air discharge:
4 kV
8 kV
8 kV
8 kV
Electromagnetic
EN 61000-4-3 2)
Housing
Level 3
HF ? eld
Frequency:
Field strength:
80 - 1000 MHz
10 V/m
80 - 1000 MHz/1.4 - 2.0 GHz
10 V/m
Fast transients
(burst)
Surge current loads
Conducted
interference
EN 61000-4-4 3)
EN 61000-4-5 3)
EN 61000-4-6 2)
Input:
Output:
Input:
Output:
I/O:
Frequency:
2 kV
2 kV
2 kV
1 kV
0.5 kV
0.5 kV
0.15 - 80 MHz
asymmetrical 5)
asymmetrical 5)
asymmetrical 5)
symmetrical 4)
asymmetrical 5)
symmetrical 4)
asymmetrical 5)
4 kV (Level 4)
2 kV (Level 3)
2 kV (Level 3)
1 kV (Level 3)
0.5 kV (Level 1)
0.5 kV (Level 1)
Level 3
0.15 - 80 MHz
U 0 :
10 V
10 V
Voltage dips
EN 61000-4-11 3)
Input:
30% reduction of the input
See input data:
voltage for 0.5 periods
Mains buffering
> 20 ms
Simulation of
radiophone
EN 50204
Frequency:
Field strength:
Not required
900 MHz/1800 MHz
20 V/m
Noise Emission According to EN 50081-2:
Radio interference
Radio interference
EN 55011
EN 55011
Class A 6)
Class A 6)
EN 55011 (EN 55022) Class B 7)
EN 55011 (EN 55022) Class B 7)
EN 55011 corresponds to CISPR11/EN 55022 corresponds to
CISPR22
Criterion A: Normal operating characteristics within the speci ? ed
EN 61000 corresponds to IEC 1000
2)
4)
5)
symmetrical: Cable to cable
asymmetrical: Cable to ground
3)
limits.
Criterion B: Temporary adverse effects on the operating
characteristics that the device corrects
6)
7)
Class A:
Class B:
Industrial application
Industrial and domestic applications
PHOENIX CONTACT page 3 of 8
